- SIZE : 6.0" x 17" (View engineered drawings below for application/fitment confirmation)
- AXLE DIAMETER : Designed for use with a 25mm axle
- WEIGHT : 8.60 lb. (3.90 kg) with sprocket carrier and hardware (no sprocket)
Add 1.05 lbs. (0.476 kg) with Worldwide Bearings ceramic bearings - BEARINGS : Ceramic wheel bearings included
- STATIC LOAD RATING : 617 lb. (280 kg)
Click Here: Important Load Rating Safety Information - MATERIALS : Carbon fiber and aluminum
- STYLE : Straight, seven-spoke configuration
- VALVE STEMS : BST Ultra-High-Speed (UHS) 90-degree, aluminum stems and caps
- APPROVALS : Race use only (see tab above for more details)
- FITMENT : View engineered drawings (Aftermarket sprocket required: Vortex Aluminum or CeraCarbon Hybrid)
- CHAIN DRIVE : Designed for use with Trask Performance Chain Drive Offset Front Sprocket - 25 Tooth (SKU: 457176)
- SWINGARM : Direct bolt in to our Performance and West Coast Bagger series swingarms using the above front sprocket and rear brake hanger that mimics the OEM width of 1.605 in (40.76mm)
- ABS : Not compatible with OEM Harley-Davidson ABS
- BRAKE ROTOR PCD : 5 x 3.25” (82.5mm)
- WARRANTY : 2 Years
- Installation may require customization and should be performed by a specialty shop
Race Use Only: These wheels were designed for use on ultra-lightweight baggers in closed course competition. Any other use is not recommended.
