- SIZE : 5.5" x 18"
- WEIGHT : 11.00 lb. (5.00 kg)
Add .60 lb. (0.27 kg) with Worldwide Bearings ceramic bearings
Add .65 lb. (0.30 kg) with Worldwide Bearings steel bearings - STATIC LOAD RATING : 640 lb. (290 kg)
Click Here: Important Load Rating Safety Information - MATERIALS : Carbon fiber and aluminum
- STYLE : Straight, five-spoke configuration
- VALVE STEMS : BST Ultra-High-Speed (UHS) 90-degree, aluminum stems and caps
- APPROVALS : DOT E and JWL for street and track use
- FITMENT : Direct OEM replacement (see 'Fitment' tab for additional models)
- BRAKE ROTOR PCD : 5 x 5.0” (127mm)
- PULLEY BEARING : Available in Steel and Ceramic (sold separately)
- WARRANTY : 2 Years
Additional Model Fitment:
- V-Rod - VRSCA (02-06)
- V-Rod - VRSCB (04-05)
- V-Rod - VRSCAW (2007)
- V-Rod CVO - VRSCSE (05-06)
- V-Rod Screamin' Eagle - VRXSE (06-07)
- V-Rod Screamin' Eagle Tribute - VRSCX (2007)
- Night Rod - VRSCD (06-07)
- Night Rod Special - VRSCDX (2007)
- Street Rod - VRSCR (06-07)
Note: V-Rod models equipped with OEM laced wheels may require the purchase of brake rotors. See Brake Rotor pitch circle diameter (PCD) for details.
